Camping & boat Solar Controler 15A MPPT Charge Controller
15A MPPT Charge Controller

15A MPPT Charge Controller

Options

Variants that match your options:

Price
Not available

In stock: 1

This value doesn't have the right number of decimals. This value is too small. This value is too large. This is required. Invalid value.

You will be notified when this product gets stocked.


(optional)
(optional)
(optional)

Your price inquiry has been submitted.

  • Secure payment by card.
  • E-mail us, we reply quickly!
  • Pay securely with Paypal.
  • Fast and safe Transport.

Description

Article no.: SFMT1550EU

Battery Parameters - System voltage 12V - Max charging current 15A - MPPT charging voltage <14.5V@25℃ - Boost voltage 14.5V@25℃ - Equal voltage 14.8V@25℃ - Float voltage 13.7@25℃ - Low voltage disconnect 10.8~11.8V;SOC1~5 - Low voltage reconnect 11.6~12.8V - Over charge protect 15.5V - Max battery voltage 20V - Temp compensation -4.17mV/K per cell(Boost,Equal),-3.33mV/K per cell(Float) - Battery type AGM, Liquid, GEL Panel Parameters - Max solar voltage 35V - Max input power 200W - Dusk/Dawn detect volt. 8.0V - MPPT tracking range (Battery Voltage+1.0V)~Voc*0.9* Load - Output current 10A - USB interface 5V, 2A - Work mode Standard, D2D, Street lamp, User-defined mode System Parameters - Max tracking efficiency >99.9% - Max charge conversion 96.5% - Dimensions 189*96*53 mm - Weight 480g - Self consumption 7mA - Ambient temperature -20~+55°C - Storage temperature -25~+80℃ - Ambient humidity 0~100%RH - Protection degree IP32 - Max altitude 4000m
